| Unfolded Dimension | W442×L412×H124mm | Folded Dimension | W179×L356×H124mm | |
| Diagonal Distance | 530mm | Weight no-battery | 2100g | |
| Payload | 6kg | Propellor | 13-inch 3 blades Paddle
|
|
| Battery | 29.6V 8S 16000mAh Weight 1940g | Drivetrain | Motor Model： T4 – 13
ESC Model： 8S 100A 4in1 |
|
| Flight Speed | GPS Mode-100km/h
Altitude Hold Mode-140km/h |
Flight Distance | 30km Total Mileage | |
| Location System | GNSS 三模 Triple-Mode | Terminal Guidance Distance | Animal 300m / Car 800m | |
| Operating Temperature | -10℃~40℃ | RC Frequency Band | 2400~2476MHz跳频 Frequency Hopping
5725~5829MHz跳频 Frequency Hopping |
|
| Battery Life | Without Payload ≈ 50min
Payload 3kg ≈ 25min Payload 6kg ≈ 13min |
|||
| Gimbal Lens Parameters | ||||
| Visibal Light Lens | Resolution | 2560×1440 | RTSP stream resolution | 1280×720 |
| Thermal Imaging Lens | Resolution | 384×288 | Focal Length | 7mm |
| Aperture | F 1.0 | FOV | 24.8°×18.7° | |
