| Unfolded Dimension | W360×L328×H95mm | Folded Dimension | W140×L314×H95mm |
| Diagonal Distance | 426mm | Weight no-battery | 1420g |
| Payload | 4kg | Propellor | 10-inch 2 blades Folding Self-locking Paddle |
| Battery | 29.6V 8S 8000mAh Weight 1500g | Drivetrain | Motor Model： T3 – 10
ESC Model： 8S 80A 4in1 |
| Flight Speed | GPS Mode-100km/h
Altitude Hold Mode-140km/h |
Flight Distance | 20km Total Mileage |
| Location System | GNSS 三模 Triple-Mode | Terminal Guidance Distance | Animal 300m / Car 800m |
| Operating Temperature | -10℃~40℃ | RC Frequency Band | 2400~2476MHz Frequency Hopping
5725~5829MHz Frequency Hopping |
| Battery Life | Without Payload ≈ 35min
Payload 2kg ≈ 15min Payload 4kg ≈ 10min |
||
| Gimbal Parameters | |||
| Dimension | 62×65×86mm | Weight | 117g |
| Operating Temperature | -10℃~50℃ | Zoom Multiple | 30X |
| Photo/Video Resolution | 2560×1440 | Control Accuracy | 0.1° |
